Section 4
Operation
20412948
8-2012/Rev 04
4-11
4.10 Run Screen Alarms
In an alarm state, the last alarm sensed by the machine will be displayed on the Run Screen. If
multiple alarm conditions have occurred they can be viewed on the Alarms Screen. Run Screen
alarms are listed in Table 4-3.
Figure 4-14: Run Screen Alarm
Table 4-3
Run Screen Alarms
Alarm Indication Comments
Bleed High Pressure
Lines
Intensifier is shut down, high pressure
is present in the discharge plumbing
and should be bled off to avoid
possible injury
Applies only when equipped with
optional pressure transducer
Booster Temperature
High
Booster pump water temperature is
high, in excess of 128 F (53 C).
Shutdown will occur if condition
persists.
High Oil
Temperature
High hydraulic oil temperature, in
excess of 144 F (62 C)
Shutdown will occur if condition
persists.
High Pressure
Warning
Output pressure is above 64,000 psi
(4,413 bar)
Applies only when equipped with
optional pressure transducer
