Section 12
Parts List
20413146
8-2012/Rev 12
12-12
Table 12-6
Hydraulic Piston Assembly
05146576
Item
Part
Number Description Quantity
1 05144589 Hydraulic Ram Piston 1
2 05074380 Plunger Retainer Pin, Clevis 12
3 05049887 Set Screw, Socket, 3/8-16 x 3/8 2
4 10148757 Check Valve 2
5 49877509 Adhesive, Thread Locker --
6 05130216 Flat Snap Ring, .032 x .375 x 2.20 2
7 05146568 Backup Ring, 1.50 x 1.75 x .125 2
8 10074821 O-Ring, 1.50 x 1.75 x .13 2
9 05120118 Seal Assembly 1
10 05120100 Bearing Ring 2
80085079 Rebuild Kit
Includes Items 4, 6, 7, 8, 9 and 10
To Next Page
