Section 12
Parts List
20413146
8-2012/Rev 12
12-16
Table 12-8
Low Pressure Water Filter Assembly
80087976
Item
Part
Number Description Quantity Item
Part
Number Description Quantity
3 05070982 Relief Valve, 50-150 psi 1 11 05135652 Check Valve 1
4 49838386 Pipe Nipple, .75 x 4.0 2 12 49833882 Adapter, Hose/ORB, .50 x .50 3
5 10119253 Elbow, Pipe, .50 x .50 1 13 95838314 Lock Washer, .25 4
6 20413848 Low Pressure Manifold, Outlet 1 14 49834716 Filter Element, 10 Micron 1
7 49833924 Low Pressure Manifold, Left 1 15 95391322 Flat Washer, .25 4
9 49835804 Adapter, Hose/Pipe, .50 x .50 2 16 10083384 U-Bolt, .75 2
10 72118339 Filter Housing Assembly 1
Ref 1
05073630 Mounting Bracket --
72121304 Cap Nut Gasket
72121296 Filter Head Gasket
