Section 12
Parts List
20413146
8-2012/Rev 12
12-24
Table 12-12
Hydraulic Hose Connections
05142351
Item
Part
Number Description Quantity Item
Part
Number Description Quantity
1 05106950 Hydraulic Hose Assembly, .75 x 19.0 1 8 05112750 Hydraulic Hose Assembly, .25 x 26.0 1
2 05106968 Hydraulic Hose Assembly, 1.25 x 26.50 1 9 05051214 Hydraulic Hose Assembly, .25 x 39.0 1
3 05106976 Hydraulic Hose Assembly, 1.25 x 24.50 1 10 80079809 Adapter, FSOR/ORB, 1.0 x .75 2
4 20419045 Hose Clamp, 3.0 4 11 80079536 Hydraulic Hose Assembly, 1.0 x 36.0 2
5 10079754 Radiator Hose, 2.50 10.5" 12 80085889 Hydraulic Hose Assembly, .25 x 20.0 1
6 49872245 Split Flange, 2.50 1 13 05061163 Hydraulic Hose Assembly, .75 x 31.0 1
7 05106984 Adapter, Flange/Hose, 2.50 x 2.50 1 14 05049713 Hydraulic Hose Assembly, .75 x 27.0 1
