KMT Streamline SL-V Plus series - Page 200

Section 12
Parts List
20413146
8-2012/Rev 12
12-28
Table 12-14
Bulkhead Pipe Assembly
80079668
Item
Part
Number Description Quantity Item
Part
Number Description Quantity
1 49887011 Adapter, JIC/Pipe, .50 x .50 3 20 49830714 Adapter, Hose/Pipe, .25 x .25 2
2 10091866 Water Modulating Valve 1 21 95157418 Adapter, JIC/Pipe, .50 x .50 1
3 05060207 Pipe Nipple, .50 x 5.0 1 22 49834302 Adapter, Pipe/Tube, .50 x .50 1
4 10100436 Coupling, Pipe, .50 x .50 2 23 10078335 Coupling, Pipe, .25 x .13 1
5 05024815 Solenoid Valve, 24V DC 1 24 95680922 Adapter, JIC/Pipe, .50 x .50 4
6 49886922 Adapter, Bulkhead, .50 x .50 5 25 10189025 Adapter, Hose/JIC, .50 x .50 5
7 20421272 Hose, Push On, .50 230.0" 26 95416319 Hex Head Screw, 3/8-16 x 1 16
8 49888035 Solenoid Valve, 24V DC 1 27 95750394 Lock Washer, .38 16
9 10070092 Jam Nut, 1-14 5 28 49833882 Adapter, Hose/ORB, .50 x .50 1
10 10073823 Tee, .50 x .50 1 29 10077030 Adapter, Tube/Pipe, .25 x .13 2
11 20413789 Manifold, LP Water Inlet 1 30 10079903 Tube, Clear, .25 36.0"
12 80087976 LP Water Filter Assembly 1 31 49834310 Adapter, Pipe/Tube, .50 x .50 1
13 49834328 Adapter, Pipe/Tube, .50 x .25 1 32 05113964 Grommet, 1.75 6
14 10173805 Hose Barb, .50 x .50 5 33 10084523 Pipe Nipple, .50 x 4.0 1
15 10079713 Hose Barb, .50 x .50 2 34 05139506 Pressure Gauge, 0-200 psi 2
16 10077055 Coupling, Bulkhead, .94 x .25 1 35 61126172 Hose, Push-on, .25 72.0”
17 05140751 Pressure Switch, 30 psi 1 36 20412815 Filter, In-Line Strainer 1
18 05111406 Adapter, JIC/Pipe, .50 x .25 2 37 49830722 Adapter, Hose/Pipe, .25 x .25 2
19 10069714 Flat Washer, .38 16 38 95146429 Hex Nut, #8-32 4
