Section 12
Parts List
20413146
8-2012/Rev 12
12-31
Table 12-15
Cover Assembly
80074768
Item
Part
Number Description Quantity
1 80074750 Support Assembly 1
2 80074735 Multi-Pin Hinge 1
3 80074727 Cover, Top 2
4 49834708 Cover, Left End 2
5 49834690 Cover, Right End 2
7 49837511 Mounting Bracket 4
8 49837529 Mounting Bracket 4
9 49837503 Spring, Gas 4
10 49837743 Button Head Screw, 3/8-16 x 1.0 32
11 05091988 Flange Nut, 3/8-16 32
12 95897948 Button Head Screw, 10-24 x 1/2 24
13 49832181 Flange Nut, #10-24 24
14 80074719 Gasket, Not Shown 1
15 95670972 Lock Washer, .38 6
16 05091954 Button Head Screw, 3/8-16 x 1.00 6
17 80076748 Cable, Lanyard, 18.75 4
18 49837826 Handle, Pocket Pull, Flush 4
