Section 12
Parts List
20413146
8-2012/Rev 12
12-33
Table 12-16
Electrical Assembly
49830938
Item
Part
Number Description Quantity Item
Part
Number Description Quantity
1 05148531 Harness, Sensor/Solenoid Cable 1 11 05113923 Ring Terminal, #6 1
2 10098804 Flexible Conduit Connector, 2.0 1 12 95716890 Lock Washer, .50 4
3 80080237 Terminal Lug, #14-2/0 9 13 10125912 Cable Tie, .87 5
4 10098788 Flexible Conduit, 2.0 42.0” 14 Starter/Control Panel Configuration 1
5 10114932 Flexible Conduit Connector, 2.0 1 15 80078140 Conduit Reducing Bushing, 2.50 x 2.0 1
6 05147251 Conduit Bushing, 2.0 x 2.0 1 16 05107347 Conduit Locknut, 2.50 1
7 10069763 Flat Washer, .50 4 17 05112545 Conduit Locknut, 2.50 1
8 05014972 Weld Cable, #4 504.0” 18 10098937 Gasket Assembly, Flexible Conduit, 2.0 1
9 49886583 Wire, #6, Green 84.0” 19 05149778 Connector, Crimp Pin, #4 12
10 95423695 Hex Nut, 1/2-13 4 20 05141007 Connector, Crimp Ferrule, #6 12
To Next Page
