4.3 Landing legs
Landing legs can be divided into two types, namely spindle support legs and fall support legs.
Spindle support legs
The legs support the trailer when
the trailer is uncoupled and can be
usedtoadjusttheheightofthe
trailer for coupling and uncoupling.
The legs have two speed settings.
Fall support legs
The legs support the trailer when
the trailer is uncoupled. The height
canonlybeadjustedincoupled
state.
Warning: Avoid limbs becoming trapped between the ground and the landing legs when lowering the legs.
A level and solid surface is required.
4.3.1 Operation of the spindle support legs
• A slight turning movement makes switching easier.
• Be aware of a possible recoil of the crank.
• Payattentiontothemaximumheightposition(crankforceincreases)!
Description
Remove the crank from the hanging hook (1) and
position the support at axle height.
1
Use only to bridge ground clearance.
Fast extending and retracting the unloaded landing leg.
Pull the crank towards you.
Before the support foot touches the ground, switch over to
the low speed setting.
Slowly lift and lower both a loaded and an unloaded
vehicle, press the crank.
