Knapen Trailers K200 - Operating the moving floor (E-operation)

42
5 Use moving oor trailer
5.7 Operating the moving oor (E-operation)
Incaseofmalfunctioningofthecontrol,seeCh7.3
Control valve E-control
1 Threaded rod
1
2
3
4
2 ValveG02Function:unloading/loading
3 ValveGS02Function:on/off
4 Pressure relief valve
5.7.1 CF7 switch (switch on the trailer)
TheCF7isthexedswitchthatismountedinthecontrolboxandisequippedwitha3-positionswitch.
Functions:
I
Loading:isactivatedwhenyouturntherotary
switchcounter-clockwise.
0
The rotary switch automatically returns to this
position when you release it.
II
Unloading: is activated when you turn the rotary
switch clockwise.
Forsafety,thisswitchisequippedwithanautomaticspringreturnforpositionsIandII,sothatitalwaysreturnsto
thecentre"0"position.ThisisnecessarytopreventafunctioningthatconictswiththeCF8remotecontrol.
At the front of the CF7 switch is a connector to which the CF8 switch can be
connected. The CF7 switch can be used if the CF8 switch malfunctions
5.8.1 CF8 switch (remote control)
Functions:
Red button: The emergency button. Press to activate and
turntotherighttodeactivate,thebuttonthenjumpsback
automatically.
Rotary switch:thisisathree-positionrotaryswitch.
Loading:isactivatedwhenyouturntherotaryswitch
counter-clockwise.Therotaryswitchautomaticallyreturns
to the centre position when you release it.
Centre position
STOP
Unloading: is activated when you turn the rotary switch
clockwise. To stop the system, turn the rotary switch back
to position 0 or operate the red stop button.
