53
User Manual EN | v201906
5.12 Sidewall protection sheet (option)
Roll out
1
Loosen the belt and elastic straps.
Use the sheet stick for the elastic straps
2 Unlock the rotating mechanism
3
Pull out the mechanism to prevent damage during operation
Turn the sheet down and take an appropriate distance for easy
operation
Roll up
1
The dirty side of the sheet must be placed against the dirty side of the
sheet when it is rolled up so that it does not touch the trailer
2
Secure the roll with the sheet in the top position
using elastic straps and the belt
3
Slide the mechanism in to prevent damage to the cab
Press the rotating mechanism back into the holder and lock the
winding mechanism using the belt
