Knapen Trailers K200 - Floor Sheet (Option)

38
5 Use moving oor trailer
5.5 Floor sheet (option)
Fortransportingsharploadsthatreleaseverynedust(forexample,lime),usearoll-upsheettoprotectthe
movingoor.Whenloadingandunloadingwithoutroll-upsheet,avoidsharpproductssuchasglassasthiswill
causeunnecessaryweartothesealing.(WiththeexceptionoftheDura-Floor,see5.4.1)
Theoorsheet(A)isstoredunderthetrailerinaplasticstoragetube(B)
A
B
5.5.1 Installation of the oor sheet
Mounting
Mount the brackets at the end of the trailer
on the left (1) and right (2)
1 2
Loosen the wing nut and open the bracket (3)
Placetheoorsheet(4)andclosethetubeholders
(5).
3
4
5
When closing the tube holders, the rotation
blockagemustremainopensothattheroll-up
sheet can turn (6).
6
Installtheairwrench(7)
7
