9.3 Floor system
System CF500
SLC
CF100
SLL
CF500
Power speed
CF3 LP-2
(Leak Proof)
CF600
HDC
CF800
HD-6
Bore (mm [inch]) 100 [3.9] 80 [3.15] 100 [4] 125 [4.9] 120 [4.7] 100 [3.9]
Piston rod diameter (mm [inch]) 45 [1.77] 35 [1.38] 45 [1.77] 60 [2.35] 45 [1.8] 50 [2]
Stroke (mm [inch]) 200 [8] 150 [5.9] 200 [8] 150 [5.9] 200 [8] 200 [8]
Cylinder volume ltr. [gallon] 2.82 [0.7] 1.36 [0.4] 2.82 [0.75] 3.26 [0.9] 4.2 [1.1] 5.5 [1.5]
Oil volume per cycle (ltr. [gallon] 8.46 [2.2] 4.09 [1.1] 8.46 [2.25] 9.77 [2.6] 12.6 [3.3] 16.5 [4.4]
Pressure relief valve setting, max.
pressure (bar [psi]) 225 [3.300] 175 [2.538] 225 [3.300] 150 [2.175] 205 [2973] 225 [3.300]
Strokes per minute with advised
pump capacity 13 17 21 11 8.7 6.6
Speed (mtr. / min [ft./min]) with
advised pump capacity 2.6 [8.5] 2.6 [8.5] 4.2 [13.8] 2.0 [6.6] 1.7 [5.6] 1.3 [10]
Advisedpumpcapacity:
Flow (ltr./min [gpm] 110 [29] 70 [18.5] 180 [47.6] 130 [34] 110 [29] 110 [29]
Pressure (bar [psi]) 250 [3.625] 200 [2.900] 250 [3.625] 175 [2.538] 205 [2973] 250 [3.625]
Max.pumpcapacity:
Flow (ltr./min [gpm]) 130 [34.5] 80 [21] 200 [52.8] 170 [45] 190 [50] 130 [34.5]
Pressure (bar [psi]) 250 [3.625] 200 [2.900] 250 [3.625] 175 [2.538] 205 [2973] 250 [3.625]
Speed at maximum pump capacity
(mtr. / min. [ft./min]) 3.1 [10] 2.9 [9.5] 4.7 [15.4] 2.6 [8.5] 3.0 [9.8] 1.6 [5.2]
9.3.1. Estimated unloading table (13.6 mtr [45 ft] trailer)
Motor Pump output Speed Unloading time
550 RPM/m [rpm] 60 l/m [15 g/min] 1.4 m/min [4.6 ft/min] 9-10minutes
750 RPM/m [rpm] 80 l/m [21 g/min] 1.9 m/min [5.9 ft/min] 7-8minutes
1000 RPM/m [rpm] 110 l/m [29 g/min] 2.6 m/min [8.5 ft/min] 5-6minutes
