5 Use moving oor trailer
5.1 General operation
Formaintenanceand/orcleaningofthemovingoor,seeCh6.7
Incaseofmalfunctionsofthemovingoor,seeCh7.1
5.2.1 Operation of the oor system
Step 1 Step 2 Step 3 Step 4
Theentiremovingoor
simultaneously slides
in the chosen transport
direction by means of the
3 hydraulic cylinders and
transports the load
1st group of moving
oorprolesispushed
back under the load by
1 hydraulic cylinder (1/3
oftheoor),atthesame
time 2/3 of the moving
oorisstationarysothe
load will hardly move, if
at all
2nd group of moving
oorprolesispushed
back under the load by
1 hydraulic cylinder (1/3
oftheoor),atthesame
time 2/3 of the moving
oorisstationarysothe
load will hardly move, if
at all
3rd group of moving
oorprolesispushed
back under the load by
1 hydraulic cylinder (1/3
oftheoor),atthesame
time 2/3 of the moving
oorisstationarysothe
load will hardly move, if
at all
The frequency and the speed at which these steps are repeated depends on the hydraulic pump output. The
available power that can be used to move the load depends on the available pressure of the hydraulic pump and
theadjustmentofthepressurereliefvalve.
Theprincipleworksintwodirections,sothatyoucanunloadbutalsoloadwiththemovingoorsystem.
Requirements for the CF500 hydraulic system
Min 150 L
PTO
Temp.
max.
70°C
M
P
T
Ø 20 x2
Ø 25 x2
max. 110 L/min
250 bar
5
4
3
2
1
1 Pressure relief
valve
250 bar
2 Pump capacity 110L per min
3 Tank content 150L
4 Pressure line ⌀20mmx2
5 Return line ⌀25mmx2
FortechnicalspecicationsCargoFloorSystemseeCh9.3
