Knapen Trailers K200 - Page 40

40
5 Use moving oor trailer
5.5.3 Floor sheet position
Theoorsheetbracketscanbeplacedindifferentpositions.Anoperatingpositionandadrivingposition.
Toseetherearlightsproperly,theoorplatemustbeintheupperpositionwhiledriving.
Operating position Driving position
Switch to driving position
There is one driving position (1) in the holder and
therearetwooperatingmodes(2-3).
Which operating position you use makes no
difference.
2
1
3
To switch between positions, simply pull out the
knob and turn the bracket to the desired position.
Tighten the wing nut well and use the rotation
block to prevent the tube from turning while
driving.
Itisnotpermittedtodrivewithaoorsheetwhen
it is not in use.
