User Manual EN | v201906
Release top beam - Tico snap fastener
1
Open the Tico snap fastener by pulling the handle
from the upper beam
1
2
Unlock the locking device on the underside.
The lever serves to lock the door at the rear section
2
3
The top locking device remains closed.
This handle on the left locking bar serves to lock the
upper beam.
3
4
The upper beam now turns outward with the left
door.
