TP-6277 10/03 Specifications 3
1.4 Engine (Continued)
8E 10E 12.5E
Intake Manifold Bolt Torque—Nm (ft. lbs.) 19 (14)
Belt Tension—kg (lbs.) New: 36-46 (79-101)
Used: 25-34 (56-75)
(A used belt has been operational for 10 minutes or more.)
Main Bearing Cap—Nm (ft. lbs.) 88-102 (64-75)
Connecting Rod Bolts—Nm (ft. lbs.) Step 1: 4 (2.9)
Step 2: Turn 90 deg. more
Rear Oil Seal Carrier—Nm (ft. lbs.) 16-20 (12-15)
Flywheel—Nm (ft. lbs.) 64-70 (47-52)
Chain Tensioner—Nm (ft. lbs.) 24-25 (17-18)
Camshaft Thrust Plate—Nm (ft. lbs.) 7-9 (5-7)
Camshaft Sprocket—Nm (ft. lbs.) 16-20 (12-15)
Timing Cover—Nm (ft. lbs.) 7-10 (5-7.5)
Water Pump—Nm (ft. lbs.) 7-10 (5-7.5)
Crankshaft Pulley—Nm (ft. lbs.) 100-120 (73.4-88)
Water Pump Pulley—Nm (ft. lbs.) 100-120 (73.4-88)
Starter Motor—Nm (ft. lbs.) 35-45 (26-33)
Fuel Pump—Nm (ft. lbs.) 16-20 (12-15)
Oil Pump—Nm (ft. lbs.) 16-20 (12-15)
Oil Pump Cover—Nm (ft. lbs.) 8-12 (6-9)
Oil Pan—Nm (ft. lbs.) Step 1: alphabetical 6-8 (5-6)
Step 2: numerical 8-11 (6-8)
Step 3: alphabetical 8-11 (6-8)
(Retorque after engine has warmed up [about 15 minutes])
Oil Pan Plug—Nm (ft. lbs.) 21-28 (15-20)
Rocker Shaft Pedestals—Nm (ft. lbs.) 40-46 (30-34)
Rocker Cover—Nm (ft. lbs.) 4-5 (3-4)
Exhaust Manifold—Nm (ft. lbs.) 21-25 (15-18)
Thermostat Housing—Nm (ft. lbs.) 17-21 (12.5-15)
Governor Linear Actuator Nut—Nm (in. lbs.) 6-7 (60)
Oil Pump Pickup Tube Bracket—Nm (ft. lbs.) 20-25 (15-18)
Carburetor Mounting Bolts—Nm (ft. lbs.) 17-21 (12.5-15)
Coil Type High Output DIS Coil
Coil Output 37.0 kV minimum
Primary Resistance (at the coil tower) 0.50 - 1.0 Ohms
High Tension Leads 30,000 Ohms max. per lead
Starter Current Draw (Normal) 175 amps
Note: ISO 3046 derates apply. See Appendix D.
