KONRAD 520 - Figure G: Trim Assembly Individual Components

500 SERIES INSTALLATION MANUAL JULY 2016PAGE 36
Individual Components
Item #
Description Qty. Part #
1 Pin , Anchor 2 10-458
2 Washer 6 10-442
3 Bushing, Anchor Pin 8 10-443
4 Cylinder, Trim, Assembly OR 2 30-024
Cylinder, Trim, Assembly (with stops) 2 30-265
5 Washer 4 10-444
6 Nut 4 10-314
7 Hose, Oil (Black) 32 in. (81 cm) OR 1 10-490
Hose, Oil (Black) 48 in. (122 cm) 1 11-170
8
Hose, Oil (Gray) 32 in. (81 cm) OR 1 10-489
Hose, Oil (Gray) 48 in. (122 cm) 1 11-180
9 Hose, Braided, Trim 4 11-078
10 Spacer, Anchor Pin 2 12-535
11
Screw 4 11-278
12
Pump, Trim (Pump Only), 12 Volt OR
Pump Assembly, Trim, 12 Volt
1
10-430
30-200
Pump, Trim (Pump Only), 24 Volt OR
Pump Assembly, Trim, 24 Volt
10-690
30-054
13 Connector 1 10-331
14 Anode 2 11-277
15 Anode 2 10-434
FIGURE G: TRIM ASSEMBLY INDIVIDUAL COMPONENTS
