53
RESO (Resonance)
Resonance emphasizes the frequencies around the cuto frequency, as shown in the diagram below.
is will have no eect with a setting of 0.
At medium settings, the resonance will alter the timbre of the lter, making it sound more nasal, or
more extreme.
Low resonance value High resonance value
Note:
For some lter types, oscillation may occur within the lter when RESO (Resonance) is set
to a high value. is may cause the oscillation to continue even aer note-o. To avoid this
kind of oscillation, use V.Patch to control the resonance value using an EG, or use a lter on
the Operator Mode side.
EG2 (EG2 Int)
is sets the amount that the EG2 modulates the cuto parameter.
CTRL (EG2 Ctrl Src)
Selects the modulation source that controls the EG2 Int. e source selected here is multiplied with
EG2 Int to determine the amount of cuto modulation. (See “Control Source List”, p.78)
