50 VS-42UHD - Protocol 3000
13.3.1.12 HDCP-MOD
Functions Permission Transparency
Set:
HDCP-MOD
Administrator Public
Get:
HDCP-MOD?
End User
Public
Description Syntax
Set: Set HDCP mode
#HDCP-MODSP
inp_id,mode
CR
Get: Get HDCP mode
#HDCP-MOD?SPinp_idCR
Response
Set / Get:
~nn@HDCP-MODSP
inp_id,mode
CR LF
Parameters
inp_id – input number: 1 (HDMI In 1), 2 (HDMI In 2), 3 (HDMI In 3), 4 (HDMI In 4)
mode
– HDCP mode: 0 (HDCP Off), 3 (Mirror output – MAC mode)
Response Triggers
A response is sent to the com port from which the set (before execution) / get command was received
A response is sent to all com ports after command execution if HDCP-MOD was set by any other external
control device (device button, device menu or other) or if the HDCP mode changed
Notes
Set HDCP working mode on the device input:
HDCP not supported - HDCP Off
HDCP support changes following detected sink - MIRROR OUTPUT
K-Config Example
Disable HDCP mode on HDMI In 2:
“#HDCP-MOD 2,0”,0x0D
