Machine Description
30
Pos: 38 /BA/Einleitu ng/Technische Daten/ Technische Daten mit 2. Überschrift @ 0\mod_11955 66374865_78.doc x @ 594 @ 2 @ 1
4.6 Technical data
All information, illustrations and technical data in these operating instructions correspond to the
latest state at the time of publication. We reserve the right to make design changes at any time
and without notification of reasons.
Pos: 39 /BA/Einleitu ng/Technische Daten/ Vorsätze/Technisc he Daten: Abmessungen X- Disc 620 @ 328\mod_1426576 296733_78.docx @ 2512815 @ @ 1
Type X-Disc 620
Working width [mm] 6200
Number of mower drums (low) 12
Number of mower drums (high) 2
Drive speed [rpm] 750
Dead weight [kg] 2800
Pos: 40 /Überschrif ten/Überschrif ten 2/P-T/Schmierstoff e @ 17\mod_1236177314933_ 78.docx @ 201837 @ 2 @ 1
4.7 Lubricants
Pos: 41 /Überschrif ten/Überschrif ten 3/F-J/Füllmengen und Sch miermittelbezeic hnungen der Getriebe @ 33\mod_ 1254230622207_78. docx @ 318675 @ 3 @ 1
4.7.1 Filling Quantities and Lubrication Designations for Gearboxes
Pos: 42 /BA/Wartung/ Umwelt/Hinweis Umwelt Be triebsstoffe entsor gen und lagern @ 313\mod_1 421247863386_78.doc x @ 2418631 @ @ 1
Environment! - Disposing of consumables and storage
Effect: Environmental damage
• Keep consumables in suitable containers according to statutory provisions.
• Dispose of used consumables according to statutory provisions.
Pos: 43 /BA/Einleitu ng/Technische Daten/ Vorsätze/Technisc he Daten Betriebsstof fe X-Disc 6200 @ 140\mod_13551 44481615_78.doc x @ 1244934 @ @ 1
Lubricants
Filling
quantity
[litres]
Filtered lubricants
Bio-degradable
lubricants
L corner gearbox 2.9 PAO Mobil SHC 630
On request
Main angular gearbox 1.7
API GL4 SAE 90
Cutter bar drive gear 0.55
Cutter bar 14
