Chapter - 3 Instrument Description / 3.5 Screen Descriptions
11
3.5 Screen Descriptions
This chapter briefly describes the following screens of the polarimeter P3000:
Main Menu In the main menu the measurements are started and
the results are displayed. The buttons lead to further
submenus.
Display window for results, unit, blank as well as
instrument and system settings.
Operation of buttons via touchscreen.
Explanation of Buttons
Opens the menus for :
System settings
Instrument settings
Calibration (measurement range,
temperature sensor)
Blank
Provides the following information:
Instrument and firmware settings
Date of last calibration
Version of user interface and data
base
