Chapter - 3 Instrument Description / 3.5 Screen Descriptions
12
Prints the result shown on the display.
Starts the measurement.
Explanation of Display
Window
Measurement result of the sample with
unit.
Blank Blank used for calculation of the sample
result.
Connected printer is switched on.
The motor is switched on.
No display: motor is switched off. It
switches off automatically a few seconds
after the measurement.
The temperature
sensor is connected to the
sample polarimeter tube and the
measured temperature during sample
measurement is 20.0 °C in this example.
Explanations: see Chapter 7.4 Calibrating the
Temperature Sensor.
No temperature display: no temperature
sensor connected.
Size of the employed polarimeter tube.
Is selected in the instrument settings.
Selected wavelength (fixed setting).
