kruss P3000 - Chapter - 11 Appendix

Chapter - 11 Appendix / 11.1 Technical Specifications
63
Chapter - 11 Appendix
11.1 Technical Specifications
P3000
Measurement range
± 90°
± 259°Z
Measurement unit
Opt. rotation [°]
Int. sugar scale [°Z]
Resolution
0.01°
0.01 °Z
Accuracy
± 0.01°
± 0.01 °Z
Reproducibility 0.01°
Measurement time approx. 1 bis 3 sec.
Light source 1 LED with filter 589 nm
Wavelength
589 nm
others optional
Wavelength selection one fixed wavelength
Connection for
temperature sensor
Special polarimeter tube with temperature sensor PT100 required
Temperature
measurement
0..99.9 °C
Temperature resolution 0.1 °C
Temperature accuracy
± 0.2 °C
Temperature
measurement point
Sample in tube
Max. tube length 220 mm
