Chapter - 7 Settings / 7.2 Instrument Settings
39
Explanations
Settings/Buttons Explanations
Selection of the unit:
° Opt. Rotation.
Actual measured value.
°Z International sugar scale.
For this unit the weighted sugar sample in
g/cm³ is selected:
6.5 g/cm³
13.0 g/cm³
26.0 g/cm³
Selection of thr pre-defined polarimeter tube length:
•
100.0 mm
200.0 mm
If a temperature sensor is connected, the
temperature at the polarimeter tube is measured.
The temperature unit is selectable.
°C / °F Selection of the temperature unit for
temperature display. Selecting the unit
automatically activates temperature
display.
off No temperature sensor connected or no
temperature display.
