MAINTENANCE WORK ON CHASSIS AND ENGINE 161
700293-11
Position the rubber holder .
Fold down the combination instrument. Position the lug  in the rubber holder.
9.61Changing the high beam lamp
Note
Damage to reflectorKeep the glass of the bulb free of grease.
Clean the glass bulb with a clean cloth before mounting. Any grease on the glass will evaporate by the heat and be deposited on the
reflector.
Switch off all power consumers and switch off the engine.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 1190 RC8 and is the answer not in the manual?

KTM 1190 RC8 Specifications

General IconGeneral
Engine TypeV-Twin, 4-stroke
Displacement1195 cc
Transmission6-speed
CoolingLiquid cooled
Fuel Tank Capacity16.5 liters
Rear BrakesSingle 220 mm disc, Brembo 2-piston caliper
Seat Height805 mm
Front SuspensionWP USD Ø 43 mm
Rear SuspensionWP monoshock
Front Brakes2 x 320 mm discs, radially mounted Brembo 4-piston calipers
FrameChromium-Molybdenum tubular space frame, powder-coated
