OPERATING ELEMENTS 34
5.18Odometer menu ODO/Trip 2
400579-01
Condition
• The ignition is on.
• ROAD mode
– Press the MODE button briefly and repeatedly until ODO appears at the top left of the
info display.
ODO shows the total distance covered.
Trip 2 shows the distance covered since the last reset. For example, between two refueling
stops. Trip 2 is always running and counts up to 9999.9.
Time 2 shows the journey time on the basis of Trip 2 and resumes running as soon as a
speed signal is received.
The calculation of this value starts with the first speed signal and ends 3 seconds after the
last speed signal.
Avs 2 (average speed) is coupled with Trip 2 and Time 2.
Press the button . No function
Press the button . No function
Press the button
and the button for
3 - 5 seconds.
The display changes to the SET‑UP menu
Press the MODE but-
ton for 3 - 5 sec-
onds.
The display of Trip 2, Time 2 and Avs 2 is reset
Press the MODE but-
ton briefly.
Next display mode
