KTM 1190 RC8 - Closing the Filler Cap; Supporting Strap

To Next Page

To Previous Page

OPERATING ELEMENTS 73

5.53Closing the filler cap

700236-01

– Close the filler cap. Push down the filler cap slightly until the lock closes.

– Remove the ignition key and close the cover.

5.54Supporting strap

700244-01

The supporting strap  is provided for the passenger to hold on to.
