MAINTENANCE WORK ON CHASSIS AND ENGINE 114
9.20Footrest position
700328-01
The adjustable footrest system enables an individual setting of the footrest height and an
individual adjustment of the operating elements.
The lower footrest position enables a more comfortable knee angle, the upper footrest posi-
tion a sporting sitting position and more forward-leaning freedom for use in racing.
9.21Adjusting footrest position
Info
The footrest position must be identical on the left and the right.
700307-01
– Remove screws .
