LOCATION OF SERIAL NUMBERS 18

4.5Shock absorber part number

700225-01

The shock absorber part number  is stamped on the upper part of the shock absorber

above the adjusting ring towards the rear.

4.6Steering damper part number

700226-01

The steering damper part number  is stamped on the top of the steering damper.
