22 TECHNICAL DATA 169
Screw, gear position sensor M5x16 5 Nm (3.7 lbf ft) Loctite
®
243™
Screw, oil filter cover M5x16 6 Nm (4.4 lbf ft) –
Screw, oil pump cover, top M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Cylinder head screw M6x25 10 Nm (7.4 lbf ft) Loctite
®
243™
Plug, vacuum connection M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Remaining screws, engine M6 10 Nm (7.4 lbf ft) –
Screw, alternator cover M6x25 10 Nm (7.4 lbf ft) –
Screw, alternator cover (chain shaft
through-hole)
M6x25 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, autodecompression M6 3… 4 Nm (2.2… 3 lbf ft) Loctite
®
243™
Screw, axial lock of camshaft M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, clutch cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch slave cylinder M6x20 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, clutch slave cylinder M6x35 10 Nm (7.4 lbf ft) –
Screw, crankshaft position sensor M6x16 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, cylinder M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, engine case M6 10 Nm (7.4 lbf ft) –
Screw, ignition coil M6 10 Nm (7.4 lbf ft) –
Screw, locking lever M6x20 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, oil pump cover, bottom M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, rocker arm shaft M6x30 12 Nm (8.9 lbf ft) –
Screw, shift drum locating M6x30 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft) Loctite
®
243™
Screw, starter motor M6x20 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, stator M6 10 Nm (7.4 lbf ft) Loctite
®
243™
