22 TECHNICAL DATA 170

Screw, thermostat case M6x20 10 Nm (7.4 lbf ft) Loctite

243™

Screw, timing chain guide rail M6x30 10 Nm (7.4 lbf ft) Loctite

243™

Screw, timing chain tensioning rail M6x30 10 Nm (7.4 lbf ft) Loctite

243™

Screw, valve cover M6 10 Nm (7.4 lbf ft) –

Screw, water pump cover M6x30 10 Nm (7.4 lbf ft) –

Screw, water pump impeller M6x15 10 Nm (7.4 lbf ft) Loctite

243™

Oil jet, piston cooling M6x0.75 4 Nm (3 lbf ft) Loctite

243™

Screw plug, crankshaft clamp M8 20 Nm (14.8 lbf ft) –

Stud, exhaust flange M8 10 Nm (7.4 lbf ft) Loctite

243™

Cylinder head screw M10 Tightening sequence:

Tighten diagonally, beginning

with the rear screw on the

timing chain shaft.

Step 1

15 Nm (11.1 lbf ft)

Step 2

30 Nm (22.1 lbf ft)

Step 3

45 Nm (33.2 lbf ft)

Step 4

60 Nm (44.3 lbf ft)

Lubricated with engine oil

Oil line for oil pressure sensor M10x1 10 Nm (7.4 lbf ft) –

Oil pressure sensor M10x1 10 Nm (7.4 lbf ft) –

Plug, drain hole of water pump M10x1 15 Nm (11.1 lbf ft) –

Screw plug, oil channel M10x1 15 Nm (11.1 lbf ft) Loctite

243™

Screw plug, oil channel, for oil radiator M10x1 15 Nm (11.1 lbf ft) –
