22 TECHNICAL DATA 178

Screw, air filter box top M6 2 Nm (1.5 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, brake fluid reservoir of rear brake M6 5 Nm (3.7 lbf ft) –

Screw, chain guard M6 2 Nm (1.5 lbf ft) Loctite

243™

Screw, chain guide M6 8 Nm (5.9 lbf ft) –

Screw, chain sliding guard M6 8 Nm (5.9 lbf ft) Loctite

243™

Screw, fan hood M6 4 Nm (3 lbf ft) –

Screw, front brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, ignition lock M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, lower radiator bracket M6 8 Nm (5.9 lbf ft) –

Screw, magnetic holder on side stand M6 6 Nm (4.4 lbf ft) Loctite

243™

Screw, radiator guard M6 8 Nm (5.9 lbf ft) –

Screw, rear brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, seat lock M6 5 Nm (3.7 lbf ft) –

Screw, side cover M6 5 Nm (3.7 lbf ft) –

Screw, upper radiator bracket M6 10 Nm (7.4 lbf ft) –

Screw, voltage regulator M6 8 Nm (5.9 lbf ft) –

Screw, wheel speed sensor M6 6 Nm (4.4 lbf ft) –

Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite

2701™

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –

Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –

Screw, connection lever on frame M8 30 Nm (22.1 lbf ft) Loctite

243™

KTM 690 SMC R 2014 User Manual
