22 TECHNICAL DATA 179

Screw, foot brake lever M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, fork stub M8 15 Nm (11.1 lbf ft) –

Screw, front footrest bracket M8 25 Nm (18.4 lbf ft) –

Screw, fuel tank bracket M8 15 Nm (11.1 lbf ft) –

Screw, fuel tank, bottom M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, fuel tank, top M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, handrail M8 20 Nm (14.8 lbf ft) –

Screw, heel protector M8x12 5 Nm (3.7 lbf ft) Loctite

243™

Screw, license plate holder, top M8 20 Nm (14.8 lbf ft) –

Screw, main silencer clamp M8 12 Nm (8.9 lbf ft) Copper paste

Screw, main silencer holder M8 25 Nm (18.4 lbf ft) –

Screw, main silencer holder on fuel tank M8 25 Nm (18.4 lbf ft) –

Screw, rear footrest bracket M8x16 25 Nm (18.4 lbf ft) –

Screw, side stand bracket M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, spring holder on side stand

bracket

M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, steering stem M8 20 Nm (14.8 lbf ft) –

Screw, top triple clamp M8 17 Nm (12.5 lbf ft) –

Engine carrying screw M10 45 Nm (33.2 lbf ft) Loctite

243™

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft) Loctite

243™

Screw, engine bearer on frame M10 45 Nm (33.2 lbf ft) –

Screw, handlebar support M10 40 Nm (29.5 lbf ft) Loctite

243™
