22 TECHNICAL DATA 164
Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) –
Oil pressure regulator valve plug M12x1.5 20 Nm (14.8 lbf ft) –
Screw plug, oil channel M14x1.5 15 Nm (11.1 lbf ft)
Loctite
®
243™
Engine case stud M16x1.5 25 Nm (18.4 lbf ft)
Loctite
®
243™
Rotor nut M18x1.5 100 Nm (73.8 lbf ft) –
Nut, engine sprocket M20x1.5 80 Nm (59 lbf ft)
Loctite
®
243™
Nut, inner clutch hub M20x1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Nut, primary gear M20LHx1.5 90 Nm (66.4 lbf ft)
Loctite
®
243™
Plug, oil screen M20x1.5 15 Nm (11.1 lbf ft) –
Plug, timing chain tensioner M20x1.5 25 Nm (18.4 lbf ft) –
Plug, oil thermostat M24x1.5 15 Nm (11.1 lbf ft) –
Screw in alternator cover M24x1.5 8 Nm (5.9 lbf ft) –
22.3 Capacities
22.3.1 Engine oil
Engine oil 1.70 l (1.8 qt.) Engine oil (SAE 10W/60) (00062010035) ( p. 175)
Alternative engine oil Engine oil (SAE 10W/50)
( p. 175)
22.3.2 Coolant
Coolant 1.20 l (1.27 qt.) Coolant ( p. 174)
Coolant (mixed ready to use) ( p. 174)
