22 TECHNICAL DATA 166
Rear 2.0 bar (29 psi)
Tire air pressure with passenger / fully loaded
Front 2.0 bar (29 psi)
Rear 2.2 bar (32 psi)
Secondary drive ratio 16:42
Chain 5/8 x 1/4” X‑ring
Steering head angle 63°
Wheelbase 1,480±15 mm (58.27±0.59 in)
Seat height unloaded 925 mm (36.42 in)
Ground clearance unloaded 270 mm (10.63 in)
Weight without fuel, approx. 142 kg (313 lb.)
Maximum permissible front axle load 150 kg (331 lb.)
Maximum permissible rear axle load 200 kg (441 lb.)
Maximum permissible overall weight 350 kg (772 lb.)
22.5 Electrical system
Battery YTZ10S Battery voltage: 12 V
Nominal capacity: 8.6 Ah
maintenance-free
Fuse 58011109130 30 A
Fuse 75011088015 15 A
Fuse 75011088010 10 A
Headlight H4 / socket P43t 12 V
60/55 W
