10. - Maintenance and storage
GMD240 - 280 - 310
97
KN204BGB_G
Disc mower
Fitting
Knives can be turned over on the same disc to use
the other cutting edge or replaced. On each knife,
an arrow indicates the disc's direction of rotation.
Fast fit knives:
• Knife for disk rotating to the left (a).
• Knife for disk rotating to the right (b).
To prevent cutter bar clogging in wet conditions,
the following knives can be fitted (Non
reversible):
• Knife for disk rotating to the left (c).
• Knife for disk rotating to the right (d).
- Pivot special tool downwards to free spring plate
from screw head.
- Insert the new knife on the screw head.
- Press knife upwards and pull it towards
yourself before releasing the special tool.
• (a), (b), (c).
