2GZ/2G1-2
1-3-15
U246
Setting the finisher
Description
Provides various settings for the optional finisher, if furnished.
Purpose
Adjustment of registration stop timing in punch mode
Adjust if skewed paper conveying occurs or if the paper is Z-folded in punch mode.
Adjustment of paper stop timing in the punch mode
To adjust this item when the position of a punch hole is different from the specified one.
Adjustment of front/rear side registration home position of internal tray
Provides optimization when paper jam occurs due to an inferior fitting of the internal tray adjuster guides to paper.
Adjusting of front and back/slanted stapling home position
Adjusts the stapling position in the staple mode if the position is not proper.
Provides adjustment of slanted stapling.
Adjustment of upper/lower side registration home position of centerfold unit
Provides optimization when paper jam occurs due to an inferior fitting of the centerfold adjuster guides to paper.
Adjustment of booklet stapling position
Adjusts the booklet stapling position in the stitching mode if the position is not proper.
Adjustment of center folding position
Adjusts the center folding position in the stitching mode if the position is not proper.
Start
1. Enter the maintenance mode and press the cursor up/down keys to display [U246].
2. Press the cursor right key to display the submenu screen.
3. Press the cursor up/down keys to select the item for which the preset value is to be changed.
Maintenance
item No.
Description
>Finisher
>[U246] Adjust
Submenu display Description
>>Punch Reg Adjustment of registration stop timing in punch mode
>>Punch Pos Adjustment of the paper stop timing in punch mode
>>Width F HP Adjustment of front side registration home position
>>Width R HP Adjustment of rear side registration home position
>>Staple HP Adjustment of front and back stapling home position
>>T-Staple HP Adjustment of slanted stapling home position
>>Width U HP Adjustment of upper side registration home position
>>Width L HP Adjustment of lower side registration home position
>>Staple Pos 1 Adjustment of booklet stapling position for A4/letter size
>>Staple Pos 2 Adjustment of booklet stapling position for B4/legal size
>>Staple Pos 3 Adjustment of booklet stapling position for A3/ledger size
>>Booklet Pos 1 Adjustment of center folding position for A4/letter size
>>Booklet Pos 2 Adjustment of center folding position for B4/legal size
>>Booklet Pos 3 Adjustment of center folding position for A3/ledger size
To Next Page
