Kyocera FS-C2026MFP Service Manual

2KW/2KX
2-3-14
Connector Pin Signal I/O Voltage Description
YC3 1 VBUS O 5 V DC 5 V DC power output
Connected to
USB
2 DATA- I/O - USB data signal
3 DATA+ I/O - USB data signal
4 GND - - Ground
YC8 1 CCDSW O 0/3.3 V DC CCD color/BW change signal
Connected to
CCD PWB
2 CCDSH O 0/3.3 V DC CCD shift gate signal
3 CCDCLPN O LVDS CCD clamp signal
4 CCDCLPP O LVDS CCD clamp signal
5 NC - - Not used
6 CCDRSP O LVDS CCD reset signal
7 CCDRSN O LVDS CCD reset signal
8 NC - - Not used
9 CCDPH1N O LVDS CCD shift register clock signal
10 CCDPH1P O LVDS CCD shift register clock signal
11 NC - - Not used
12 CCDPH2P O LVDS CCD shift register clock signal
13 CCDPH2N O LVDS CCD shift register clock signal
14 NC - - Not used
15 +3.3VS O 3.3 V DC 3.3 V DC power to CCDPWB
16 HPSWN I 0/3.3 V DC HPS: On/Off
17 NC - - Not used
18 +24V_LAMP O 24 V DC 24 V DC power to CCDPWB
19 LAMPTH O 0/3.3 V DC EL drive signal
20 GND_LAMP - - Ground
21 NC - - Not used
22 GND - - Ground
23 CCDDATAB I Analog CCD image output signal (B)
24 GND - - Ground
25 CCDDATAG I Analog CCD image output signal (G)
26 GND - - Ground
27 CCDDATAR I Analog CCD image output signal (R)
28 GND - - Ground
29 NC - - Not used
30 +5V1 O 5 V DC 5 V DC power to CCDPWB
31 NC - - Not used
32 +12VS O DC12V 12 V DC power to CCDPWB
