2KW/2KX
2-3-15
YC12 1 VBUS O 5 V DC 5 V DC power output
Connected to
USB
2 DATA- I/O - USB data signal
3 DATA+ I/O - USB data signal
4 GND - - Ground
5 GND - - Ground
YC14 A1 NC - - Not used
Connected to
FAX control
PWB
B1 NC - - Not used
A2 NC - - Not used
B2 NC - - Not used
A3 GND - - Ground
B3 3.3V O 3.3 V DC 3.3 V DC power output
A4 3.3V O 3.3 V DC 3.3 V DC power output
B4 A15 O 0/3.3 V DC (pulse) Address bus signal
A5 GND - - Ground
B5 A14 O 0/3.3 V DC (pulse) Address bus signal
A6 A13 O 0/3.3 V DC (pulse) Address bus signal
B6 A12 O 0/3.3 V DC (pulse) Address bus signal
A7 A11 O 0/3.3 V DC (pulse) Address bus signal
B7 A10 O 0/3.3 V DC (pulse) Address bus signal
A8 A9 O 0/3.3 V DC (pulse) Address bus signal
B8 A8 O 0/3.3 V DC (pulse) Address bus signal
A9 GND - - Ground
B9 A7 O 0/3.3 V DC (pulse) Address bus signal
A10 A6 O 0/3.3 V DC (pulse) Address bus signal
B10 A5 O 0/3.3 V DC (pulse) Address bus signal
A11 A4 O 0/3.3 V DC (pulse) Address bus signal
B11 A3 O 0/3.3 V DC (pulse) Address bus signal
A12 A2 O 0/3.3 V DC (pulse) Address bus signal
B12 A1 O 0/3.3 V DC (pulse) Address bus signal
A13 GND - - Ground
B13 3.3V O 3.3 V DC 3.3 V DC power output
A14 OP2IFN O 0/3.3 V DC Select signal
B14 OP2ACKN I 0/3.3 V DC (pulse) OP2ACKN signal
A15 OP2IRN I 0/3.3 V DC Interruption signal
B15 5V O 5 V DC 5 V DC power output
A16 RDY O 0/3.3 V DC Ready signal
Connector Pin Signal I/O Voltage Description
