Kyocera FS-C2026MFP - Page 281

2KW/2KX
2-3-17
YC32 1 FEEDCL O 0/24 V DC DPPFCL: On/Off
Connected to
DP drive
PWB
2 REVSOL O 0/24 V DC DPSBSOL: On/Off
3 PRESOLN O 0/24 V DC DPPRSOL: On (Press)/Off
4 RELSOLN O 0/24 V DC DPPRSOL: On (Release)/Off
5 DPDETN I 0/3.3 V DC DP set signal
6 OPSWN I 0/3.3 V DC DPOCS: On/Off
7 ORGSWN I 0/3.3 V DC DPOS: On/Off
8 TIMSWN I 0/3.3 V DC DPTS: On/Off
9 GND - - Ground
10 +3.3V2 O 3.3 V DC 3.3 V DC power to DPDPWB
11 GND - - Ground
12 +24V2 O 24 V DC 24 V DC power to PDPWB
13 MOTB2 O 0/24 V DC (pulse) DPPFM drive control signal
14 MOTA2 O 0/24 V DC (pulse) DPPFM drive control signal
15 MOTB1 O 0/24 V DC (pulse) DPPFM drive control signal
16 MOTA1 O 0/24 V DC (pulse) DPPFM drive control signal
YC36 1 SCMOTB2 O 0/24 V DC (pulse) ISUM drive control signal
Connected to
ISU motor
2 SCMOTA1 O 0/24 V DC (pulse) ISUM drive control signal
3 SCMOTB1 O 0/24 V DC (pulse) ISUM drive control signal
4 SCMOTA2 O 0/24 V DC (pulse) ISUM drive control signal
YC37 1 +24V1 I 24 V DC 24 V DC power from PSPWB
Connected to
power source
PWB
2 GND - - Ground
3 GND - - Ground
4 +5V1 I 5 V DC 5 V DC power from PSPWB
YC38 1 GND - - Ground
Connected to
laser scanner
unit KM
2 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB-M
3 PDMN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
4 VDOMP O LVDS APCPWB-M video data signal (+)
5 VDOMN O LVDS APCPWB-M video data signal (-)
6 GND - - Ground
7 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB-K
8 PDKN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
9 VDOKP O LVDS APCPWB-K video data signal (+)
10 VDOKN O LVDS APCPWB-K video data signal (-)
Connector Pin Signal I/O Voltage Description
