Kyocera FS-C2026MFP - Page 282

2KW/2KX
2-3-18
YC39 1 +3.3V1_MFP O 3.3 V DC 3.3 V DC power to RYPWB
Connected to
relay PWB
2 I2CSDA I/O 0/3.3 V DC (pulse) EEPROM data signal
3 GND - - Ground
4 I2CSCL O 0/3.3 V DC (pulse) EEPROM clock signal
5 SCKN O 0/3.3 V DC (pulse) Serial communication clock signal
6 SO I 0/3.3 V DC (pulse) Serial communication data signal input
7 SI O 0/3.3 V DC (pulse) Serial communication data signal output
8 SDIR I 0/3.3 V DC Serial communication direction change
signal
9 SBSY I 0/3.3 V DC Serial busy signal
10 EGIRN I 0/3.3 V DC Engine interruption signal
11 VSYNC I 0/3.3 V DC (pulse) Horizontal synchronizing signal
12 +3.3V2 O 3.3 V DC 3.3 V DC power to RYPWB
13 GND - - Ground
14 EGHOLD O 0/3.3 V DC Engine hold signal
15 I2CINT O 0/3.3 V DC (pulse) Communication signal
16 HYPINT I 0/3.3 V DC Interruption signal
17 PSSLEEPN O 0/3.3 V DC Sleep mode signal: On/Off
YC40 1 GND - - Ground
Connected to
laser scanner
unit CY
2 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB-Y
3 PDYN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
4 VDOYP O LVDS APCPWB-Y video data signal (+)
5 VDOYN O LVDS APCPWB-Y video data signal (-)
6 GND - - Ground
7 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB-C
8 PDCN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
9 VDOCP O LVDS APCPWB-C video data signal (+)
10 VDOCN O LVDS APCPWB-C video data signal (-)
YC41 1 +24V1 O 24 V DC 24 V DC power to CONFM
Connected to
controller fan
motor
2CONTFAN
DRN
O 0/12/24 V DC CONFM: Full speed/Half speed/Off
YC42 1 +24V1 O 24 V DC 24 V DC power to RFM
Connected to
right fan
motor
2 RFANDRN O 0/12/24 V DC RFM: Full speed/Half speed/Off
Connector Pin Signal I/O Voltage Description
