YC43 1 +5V1 - 5 V DC 5 V DC power to OPPWB
Connected to
operation
panel PWB
2 POWERKEY I 0/3.3 V DC Power key input signal
3 FPRSTN O 0/3.3 V DC OPPWB reset signal
4 PANTXD O 0/3.3 V DC (pulse) OPPWB transmission data
5 PANRXD I 0/3.3 V DC (pulse) OPPWB received data
6 +3.3V O 3.3 V DC 3.3 V DC power to OPPWB
7PANEL_
MODE1
O 0/3.3 V DC OPPWB mode signal
8 GND - - Ground
9PANEL_
MODE0
O 0/3.3 V DC OPPWB mode signal
YC44 1 TCT O 3.3 V DC 3.3 V DC power output
Connected to
ethernet
2 TD+ O 0/3.3 V DC (pulse) Transmission data
3 TD- O 0/3.3 V DC (pulse) Transmission data
4 RD+ I 0/3.3 V DC (pulse) Received data
5 RD- I 0/3.3 V DC (pulse) Received data
6 RCT O 3.3 V DC 3.3 V DC power output
7 CAT PHY O 0/3.3 V DC Control signal
8 ANO PHY O 3.3 V DC 3.3 V DC power output
9 CAT MAC - - Ground
10 ANO MAC O 0/3.3 V DC Control signal
Connector Pin Signal I/O Voltage Description
