Kyocera FS-C2026MFP Service Manual

2KW/2KX-1
1-3-18
U410 Adjusting the halftone automatically
Description
Carries out processing for the data acquisition that is required in order to perform either auto-
matic adjustment of the halftone or the ID correction operation.
Purpose
Performed when the quality of reproduced halftones has dropped.
Method
1. Select [Normal Mode].
2. Press the start key. A test patterns 1 and 2 are outputted.
3. Place the output test pattern 1 as the original.
Place approximately 20 sheets of white paper on the test pattern 1 and set them.
4. Press the start key.
Adjustment is made (first time).
5. Place the output test pattern 2 as the original.
Place approximately 20 sheets of white paper on the test pattern 2 and set them.
6. Press the start key.
Adjustment is made (second time).
7. When normally completed, [Finish] is displayed.
If a problem occurs during auto adjustment, error code is displayed.
Error codes
Completion
Press the stop key. The screen for selecting a maintenance item is displayed.
Item No. Description
Codes Description Codes Description
S001 Patch not detected E001 Engine status error
S002 Original deviation in the main
scanning direction
E002 Engine sensor error
EFFF Engine other error
S003 Original deviation in the auxil-
iary scanning direction
C001 Controller error
C100 Adjustment value error
S004 Original inclination error C200 Adjustment value error
S005 Original type error CFFF Controller other error
SFFF Scanner other error

Kyocera FS-C2026MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total output capacity	- sheets
Maximum input capacity	50 sheets
Internal memory	768 MB
Processor family	PowerPC
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	50 dB
Dimensions (WxDxH)	514 x 550 x 580 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Maximum internal memory	1.75 GB
Color all-in-one functions	copy, print
Compatible operating systems	Windows, Mac OS X 10.2 +, Unix, Linux
Maximum print size	216 x 356 mm
Paper tray media types	Envelopes, Plain paper
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Certification	TÜV/GS, CE
Maximum duty cycle	65000 pages per month
Grayscale levels	256
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR
Market positioning	Business
