Kyocera FS-C2026MFP Service Manual

2KW/2KX
1-3-19
U411 Adjusting the scanner automatically
Description
Uses the adjustment original suppled with DP and automatically adjusts the following items in the
scanner and the DP scanning sections.
Scanner section: Original size magnification, leading edge timing, center line, input gamma, input
gamma in monochrome mode and matrix
DP scanning section: Original size magnification, leading edge timing, center line
Purpose
To perform automatic adjustment of various items in the scanner and the DP scanning sections.
Method
1. Press the start key.
2. Select the item. The screen for executing is displayed.
Method: Table
1. Enter the target values which are shown on the specified original (P/N: 302FZ56990) execut-
ing maintenance item U425.
2. Set a specified original (P/N: 302FZ56990) on the platen.
3. Enter maintenance item U411.
4. Select [Table] using the cursor up/down keys.
5. Press the start key. Auto adjustment starts.
6. When automatic adjustment has normally completed, [OK] is displayed. If a problem occurs
during auto adjustment, [NG XX] (XX is replaced by an error code) is displayed and operation
stops. Should this happen, determine the details of the problem and repeat the procedure
from the beginning.
7. To return to the screen for selecting an item, press the stop key.
Method: DP
1. Select [DP] using the cursor up/down keys.
2. Set a specified original (P/N: 303LJ57010) in the DP.
3. Press the start key. Auto adjustment starts.
4. When automatic adjustment has normally completed, [OK] is displayed. If a problem occurs
during auto adjustment, [NG XX] (XX is replaced by an error code) is displayed and operation
stops. Should this happen, determine the details of the problem and repeat the procedure
from the beginning.
5. To return to the screen for selecting an item, press the stop key.
Item No. Description
Display Description Original to be used
for adjustment (P/N)
All Performs automatic adjustment in the DP
scanning section following automatic
adjustment in the scanner section
302FZ56990/
303LJ57010
Table Automatic adjustment in the scanner sec-
tion
302FZ56990
DP Automatic adjustment in the DP scanning
section:
303LJ57010

Kyocera FS-C2026MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total output capacity	- sheets
Maximum input capacity	50 sheets
Internal memory	768 MB
Processor family	PowerPC
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	50 dB
Dimensions (WxDxH)	514 x 550 x 580 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Maximum internal memory	1.75 GB
Color all-in-one functions	copy, print
Compatible operating systems	Windows, Mac OS X 10.2 +, Unix, Linux
Maximum print size	216 x 356 mm
Paper tray media types	Envelopes, Plain paper
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Certification	TÜV/GS, CE
Maximum duty cycle	65000 pages per month
Grayscale levels	256
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR
Market positioning	Business
