Kyocera KM-2560 - Page 280

2H0/2HZ
2-3-10
YC20 1 +24V1 O 24 V DC 24 V DC power output to key counter
Connected
to the key
counter
2 KEYCN O 0/5 V DC Key counter signal
3SGND -- Ground
4 KEYENBN I 0/5 V DC Key counter connection signal
YC22 1 +24VIL2PF2 O 24 V DC 24 V DC power output to PWSW-L
Connected
to the upper/
lower paper
size length
switches,
optional
paper feeder
and MP feed
switch
2 +24VIL2PF1 O 24 V DC 24 V DC power output to PWSW-U
3 +24VIL2 O 24 V DC 24 V DC power output to PWSW-L
4 +24VIL2 O 24 V DC 24 V DC power output to PWSW-U
5 LODIG1 I 0/5 V DC PWSW-L: On/Off
6 HIDIG1 I 0/5 V DC PWSW-U: On/Off
7 LODIG0 I 0/5 V DC PWSW-L: On/Off
8 HIDIG0 I 0/5 V DC PWSW-U: On/Off
9 GND - - Ground
10 GND - - Ground
11 LODIG2 I 0/5 V DC PWSW-L: On/Off
12 HIDIG2 I 0/5 V DC PWSW-U: On/Off
13 GND - - Ground
14 +5VSL O 5 V DC 5 V DC power output to paper feeder
15 PFSEL O 0/5 V DC Paper feeder select signal
16 PFSCLK O 0/5 V DC (pulse) Paper feeder clock signal
17 PFSDI I 0/5 V DC (pulse) Paper feeder serial communication data signal
18 PFSDO O 0/5 V DC (pulse) Paper feeder serial communication data signal
19 PFREADY I 0/5 V DC Paper feeder ready signal
20 PFFEED O 0/5 V DC Paper feeder feed signal
21 GND - - Ground
22 BYPFEEDSW I 0/5 V DC MPFSW: On/Off
23 +5VSL O 5 V DC 5 V DC power output to MPFSW
24 N.C. - - Not used
YC23 A1 GND - - Ground
Connected
to the upper/
lower lift
limit
switches,
upper/lower
paper
switches,
upper/lower
lift motors
and upper/
lower paper
size length
switches
A2 LOLIFTSW I 0/5 V DC LICSW-L: On/Off
A3 +5VSL O 5 V DC 5 V DC power output to LICSW-L
A4 GND - - Ground
A5 LOPAPSW I 0/5 V DC PSW-L: On/Off
A6 +5VSL O 5 V DC 5 V DC power output to PSW-L
A7 LOLIFTSW2 I 0/5 V DC LM-L paper gauge signal
A8 GND - - Ground
A9 LOLIFTSW1 I 0/5 V DC LM-L paper gauge signal
A10 GND - - Ground
A11 LOLIFTREM O 0/24 V DC LM-L: On/Off
A12 LOLENGSW I 0/5 V DC PLSW-L: On/Off
A13 GND - - Ground
B1 GND - - Ground
B2 HILENGSW I 0/5 V DC PLSW-U: On/Off
Connector Pin No. Signal I/O Voltage Description
