2-1-2 Main charging section
The main charging section consists of the main charger assembly, drum and so on. The drum is electrically charged uni-
formly by means of a grid to form a latent image on the surface.
The main charger unit charges the drum so that a latent image is formed on the surface, the shield grid ensuring the
charge is applied uniformly.
Figure 2-1-5 Main charging section
Figure 2-1-6 Main charging section block diagram
Main charger unit
Shield grid
Tungsten wire
Drum
HVTPWB EPWB
Main charging
high voltage
MHVDRN
CN1-8 YC12-5
Drum
ZENER PWB
Grid
