Kyocera KM-2560

2H0/2HZ
2-4-2
Maintenance kits
Maintenance part name
Part No.
Alterna-
tive part
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Right filter PARTS HOLDER FILTER A SP 302H094400 2H094400 17 A01
Ozone filter 1 FILTER OZONE B 302H033180 2H033180 1 42
Ozone filter 2 FILTER OZONE A 302H033170 2H033170 19 38
Power source PWB PARTS LVU 100 302H093280 2H093280 21 54
Power source PWB PARTS LVU 200 302H093290 2H093290 21 54
Main PWB PARTS,PWB MAIN ASS'Y,SP 302H094010 2H094010 21 44
Maintenance part name
Part No.
Alternative
part No.
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Maintenance kit
<For 120 V specifications> MK-670/MAINTENANCE KIT 1702H07US0 072H07US 27 -
Upper/lower paper feed pulley PULLEY,PAPER FEED - - - -
Upper/lower separation pulley PULLEY,SEPARATION - - - -
MP separation pulley PULLEY,SEPARATION - - - -
Upper/lower forwarding pulley PULLEY FEED A - - - -
MP forwarding pulley PULLEY FEED A - - - -
Developing unit PARTS,DV-420,SP - - - -
Ozone filter 1 FILTER OZONE B - - - -
Ozone filter 2 FILTER OZONE A - - - -
Drum unit PARTS DK-670 - - - -
Fuser unit PARTS FK-670(U) - - - -
Transfer roller unit PARTS TR-670 - - - -
Right filter PARTS HOLDER FILTER A SP - - - -
MP paper feed pulley UPPER PULLEY,BYPASS - - - -
<For 220 - 240 V specifications> MK-670/MAINTENANCE KIT 1702H08NL0 072H08NL 27 -
Upper/lower paper feed pulley PULLEY,PAPER FEED - - - -
Upper/lower separation pulley PULLEY,SEPARATION - - - -
MP separation pulley PULLEY,SEPARATION - - - -
Upper/lower forwarding pulley PULLEY FEED A - - - -
MP forwarding pulley PULLEY FEED A - - - -
Developing unit PARTS,DV-420,SP - - - -
Ozone filter 1 FILTER OZONE B - - - -
Ozone filter 2 FILTER OZONE A - - - -
Drum unit PARTS DK-670 - - - -
Fuser unit PARTS FK-670(E) - - - -
Transfer roller unit PARTS TR-670 - - - -
Right filter PARTS HOLDER FILTER A SP - - - -
MP paper feed pulley UPPER PULLEY,BYPASS - - - -
