Kyocera KM-2560

2H0/2HZ
1-1-5
1-1-3 Machine cross section
Figure 1-1-3 Machine cross section
Paper path
Light path
3
8
9
7
6
2
5
4
1
1
1
3
1. Paper feed section
2. Main charging section
3. Optical section
4. Developing section
5. Transfer and separation section
6. Cleaning and charge erasing section
7. Fuser section
8. Eject and switchback section
9. Duplex section
