Adjustment of attenuation at the input to the PLM power stage is available on a per-channel basis. This
adjustment is the PLM equivalent of a conventional amplier level control. The power output channels may
be turned down using these parameters before powering on or off. Please refer to the signal ow diagram
in Figure 6-2 on page 27.
By default, all channels are deselected. Press the SEL ALL button to select/deselect all channels (as shown
in Figure 7-15) or, press a single button on the right to adjust a channel individually.
For four-channel PLMs, only ONE channel or ALL
channels may be adjusted. It is not possible to
adjust only two or three channels.
7.11.5 Frame Submenu
MENU > FRAME
Figure 7-16: Frame Menu
The Frame Menu provides information and options relating to the PLM as a physical unit. It is referred to as
a Frame for consistency with Lake Controller terminology.
The Frame Label as dened in the Lake Controller is displayed in this menu. It is also displayed at the
top-left of the screen in Meter Mode, Home View.
7.11.5.1 Frame Info
MENU > FRAME > FRAME INFO
Frame Info provides information about the device settings and conguration. All data in this front panel
menu is read-only; some parameters are xed, some can be changed only via the Lake Controller software.

Lab.gruppen PLM Series Specifications

General

DSP	Yes
Network	Ethernet
Connectors	XLR, SpeakON
Cooling	Forced air
Protection Features	Overheat, DC, short circuit
Control Software	Lake Controller
