Lab.gruppen PLM Series User Manual

70
Appendix
PLM Series Operation Manual rev 1.1.9
9. Appendix
9.1 Faults and Warnings Overview
Fault or warning conditions are indicated by the LED shown in Figure 7-3 on page 34, and also by LEDs associ-
ated with the inputs and outputs on the PLM. As the LEDs indicate several types of faults or warnings, a
brief textual description of the fault or warning is provided on the LCD display. Section 7.8.2 on page 34 details
the fault and warning indications that appear on the front panel. Table 9-1 lists the events that may have
triggered each fault or warning condition.
Displayed Text Event Log Text Category Type Description
AMP CH. MUTE Amp Channel Mute Mute
status
Amplier Mute The audio signal has been muted in
the power output stage.
AUDIO FAULT Frame Fault: Audio
Interface
Fault Audio interface fault An internal audio fault has arisen
and the unit needs servicing.
CAL ACTIVE n/a Fault Current Average
Limiter
Ensures that the PLM’s power
output stages are not overloaded.
This should never happen during
normal program material.
CTRL OFFLINE Frame Ofine Warning Controller/Frame
ofine
The PLM is no longer able to
communicate with the Dolby Lake
Controller.
CURRENT CLIP n/a Clip Current Protection
active
PLM’s power output stage current
has exceeded the xed safe
maximum and the Current Peak
Limiter has become active to limit
it.
INPUT CLIP n/a Clip Input clip The input signal level is too high
and is causing clipping at the input
stage
LM PREC. LOW Speakersafe precision
low
Warning SpeakerSafe precision
low
A SpeakerSafe warning indicating
insufcient data to produce
reliable results. This may occur,
for example, if a channel is being
driven at a very low level.
LOAD NOT VER LoadSmart: Load Not
Veried
Warning Load not veried A Module containing a Fingerprint
has been loaded, but the load is yet
to be veried with LoadSmart.
MOD. IN MUTE Module Input Mute Mute
status
Module Input Mute The audio signal has been muted at
the Module input of the Dolby Lake
processor.
MOD. OUT MUTE Module Output Mute Mute
status
Module Output Mute The audio signal has been muted in
the output stage of the Dolby Lake
processor.
